Moxa Technologies TCC-100 Series - Product Features; Package Checklist; Product Specifications

4
Product Features
• RS-232 to RS-422 conversion with RTC/CTS support
• RS-232 to 2/4-wire RS-485 conversion
• Detachable wall and DIN-rail mounting for easy RS-422/485 wiring
• PWR, Tx, and Rx LEDs
• E
SD protection
• 2 k
V isolation (TCC-100I/TCC-100I-T) for both power and RS-422/485
signals
• Operating temperature:
TCC-100/100I: -20 to 60°C (-4 to 140°F)
TCC-100-T/100I-T: -40 to 85°C (-40 to 185°F)
Package Checklist
Before installing the Moxa TCC-100, verify that the package contains the
following items:
• TCC-100/100I media converter
• DK-35A: DIN-rail mounting kit
• Power jack to 3-pin terminal block adaptor
• User’s manual (this document)
• Warranty card
Note: Please notify your sales representative if any of the above items are
missing or damaged.
Product Specifications
Communication
RS-232 Signal Supports Tx, Rx, RTS, CTS;
Female DB9 interface
RS-422/485 Signal Terminal block connector (DIP Switch selectable)
4-wire RS-422 (with RTS/CTS), up to 10 nodes
(1.2 km)
4-wire RS-485: up to 32 nodes (1.2 km)
2-wire RS-485: up to 32 nodes (1.2 km)
RS-485 Data Direction
Control
ADDC™
Baudrate
50 bps to 921.6 Kbps
ESD Protection
Contact: 4 kV; Air: 8 kV
Isolation
2 kV (TCC-100I/TCC-100I-T) for both power and
signal
