MPP Solar Hybrid LV 6KW User Manual

28
SPECIFICATIONS
MODEL
6KW
RATED OUPUT POWER
6000W
PV INPUT (DC)
Max. PV Power
6000W
Max. Input voltage
(Maximum PV open voltage)
450 VDC
Max. DC Power MPPT range
120 VDC~430 VDC
Max. DC Input current / per string
27A
Number of MPP Tracker
1
GRID-TIE OPERATION
GRID OUTPUT (AC)
Nominal Output Voltage
110-120VAC (L-N) / 220-240VAC (L1-L2)
Feed-in Grid Voltage Range
97~121 VAC For 110 Vac model (IEEE 1547)
106~132 VAC For 120 Vac model (IEEE 1547)
Feed-in Grid Frequency Range
59.3~60.5Hz For 60Hz (IEEE 1547)
Nominal Output Current
27.3A (for 110VAC)
25A (for 120VAC)
Power Factor Range
>0.99
Maximum Conversion Efficiency (DC/AC)
95%
OFF-GRID, HYBRID OPERATION
GRID INPUT
Acceptable Input Voltage Range
65 - 140 VAC (Appliances) or 95 - 140 VAC (UPS)
Frequency Range
50 Hz/60 Hz (Auto sensing)
Rating of AC Transfer Relay
40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
110-120VAC (L-N) / 220-240VAC (L1-L2)
Output Waveform
Pure Sine Wave
Efficiency (DC to AC)
93%
BATTERY & CHARGER
Nominal DC Voltage
48 VDC
Maximum Charging Current (from Grid)
100A
Maximum Charging Current (from PV)
100A
Maximum Charging Current
100A
GENERAL
Dimension, D X W X H (mm)
593.6 x 365 x 138.4
Net Weight (kgs)
26
INTERFACE
Parallel-able
Yes
External Safety Box (Optional)
Yes
Communication
RS232/Dry-Contact/Wi-Fi
ENVIRONMENT
Humidity
0 ~ 90% RH (No condensing)
Operating Temperature
-10°C to 50°C
