31
Line Mode
The unit will provide output
power from the mains. It
will also charge the battery
at line mode.
Power from utility only
Battery Mode
The unit will provide output
power from battery and PV
power.
Power from battery and PV energy.
PV energy will supply power to the loads and
charge battery at the same time.
Power from battery only.
Power from PV only
