MPPT SUN-MPPT-4015A User Manual

22
Specificaons6.0
Characterisaon of the operang performance
system Voltages
Maximum Solar Array
Less than 1 Wa typical
Standby Power Consumpon
98%
DC input side
PV Open Circuit Voltage (VOC) 150 volts DC
max current
45A
DC output side
charge current
45A
30A
load current
Electrical
Battery Charging
Charging algorithm 4 - stage
Charging stages Bulk, Absorption, Float, Equalize
Charging Setpoints:
Setting
Mode
Battery
Type
Absorp.
Stage
Float
Stage
Equalize
Stage
stloVstloVstloV
3Fb1 1 - Sealed 14.40 13.80
3Fb2 2 - Gel 14.10 13.50 14.40
3Fb3 3 - AGM 14.10 13.20 14.60
3Fb4 4 - Flooded 14.60 13.80 15.10
NOTE:
All charging voltage setpoints listed are for 12 Volt systems.
Multiply 2X for 24 Volt systems.
12VDC 630 Watts
24VDC 1260watts/48VDC 2688watts
SUN-MPPT-4015A
12V/24V/48V
Peak Efficiency

MPPT SUN-MPPT-4015A Specifications

General

Brand	MPPT
Model	SUN-MPPT-4015A
Category	Controller
Language	English
