Mr Handsfree Blue Compact - Page 6

GB - 6
2. Built-inconnection:Immediatelytothecar’selectronicsystemviasystemcableSC2(Optional).
 ThewiresofcableSC2arecolor-coded.TheyarelistedinTable1incolumnAandeachwireshouldbeconnectedto
thecorrespondingitemlistedincolumnB.
 Table 1

A B
Redwire The+voltageofthecar’spowersupply
Blackwire ThenegativeGNDconnection
Bluewire
Ignition
Brownwire UsedforCarRadioMuting(CRM)andhastobeconnectedtothecarradio(Mute)
• Toavoiddistortions,makesurethatthecablesarelaidfarawayfromtheelectronicsystemsofthecar.
• Connectthewireswiththecontactclips.Putthecarwireinthethroughgrooveoftheclipsandthecablewireinthe
groovewiththeconfiningrib.
Attention!
 Ifthereisno“Ignition”wireorifitisunavailable,youshouldconnectthebluecablewiretotheredwireofthehandsfree
unitandtheredcablewiretothe“
Continuous”wireofthecarwhichkeepsthevoltagewhenignitionisturnedoff.In
thiscase,thephonecallwillnotbedisconnectediftheignitionisturnedoff.
CAR RADIO MUTING (CRM)
 TheBlueCompactallowsmutingyourcarradiowhenthereisanincomingcall.
• Checktheuser’smanualofyourcarradioandensurethatithasaMutefunction.Ifadditionalsettingshavetobe
setfromthecarradiomenu,makesurethattheyaredonecorrectly.
• Removethecontrolpanelofthecarradio.
• Removethedecorativepanelandtakethecarradiooutofthesleeveusingthehandles.Disconnectthecarradioplug.
• ConnectthewiresofthemrHandsfreeBlueCompacttothecorrespondingwiresofthecarradioaccordingtoTable
1.Usethecontactclipsfortheconnection.
• Restoretheconnectionandinstallationofthecarradio.
3. Professionalbuilt-inconnection:Immediatelytothecar’selectronicsystemviasystemcableMB1(
Optional).
• Disconnectthecarradioandpowerleads.
• Jointhecableaccordingtotheconnectiondiagramshownbelow.Ifthecarradiohasamutejack,connecttheyel
-
lowwireofthecabletooneofthe“mutein”jacks(1,2or3).Refertoyourcarradiomanualtodeterminetheposition
ofthemutejack.
