Mr Handsfree Blue Compact - Page 9

GB - 9
78
56
34
12
78
56
34
12
7 8
5 6
3 4
1 2
7 8
5 6
3 4
1 2
DIN/ISO/FAKRA TO ANTENNA
JACK + MOLEX PLUG TO CARKIT
YELLOW WIRE TO MUTE FROM RADIO
*
FREQUENCY SELECTOR FOR FM
CAR SPEAKERS
CAR POWER
CAR RADIO
TO MP3 ETC. JACK 3.5/2.5 MM
FUSE 2 A
MUTE 1 MUTE 2 MUTE 3
X1 X2
Y1 Y2
POWER/MUTE Y1
1. green yellow ignition (+12V)
2. black (Ground)
3. blue (Aerial*)
4. violet (Illumination*)
5. green (Mute N1)
6. yellow (+12V) permanent
7. white (Mute N2)
8. brown (Mute N3)
SPEAKERS X2
1. green (LB+)
2. green yellow (LB-)
3. blue (LF+)
4. white (LF-)
5. yellow (RF+)
6. brown (RF-)
7. black (RB+)
8. violet (RB-)
SPEAKERS Y2
1. green (LB+)
2. green yellow (LB-)
3. white (LF+)
4. blue (LF-)
5. brown (RF+)
6. yellow (RF-)
7. violet (RB+)
8. black (RB-)
POWER/MUTE X1
1.
3.
4.
5.
6.
7. white (Mute N2)
blue (to mute box) +
green yellow (toY1) ignition (+12V)
8. brown (Mute N3)
green (Mute N1)
green yellow (to
mute box) + yellow
(to Y1) (+12V) permanent
blue (Aerial*)
violet (Illumination*)
2. black + black (Ground)
TO iPod
TO MP3-Player
(mini USB)
