mr. steam MX4E - Generator Dimensions

mr
.
steam
®
Installation, Operation & Maintenance Manuals
______________________________________________________________________________
8
All drawings are for illustrative purposes only
I
H
F
G
E
%
C
J
A
D
K
Side View Showing
Element Access Panel
18”
for servicing
L
M
STEAM GENERATOR DIMENSIONS
TO AVOID
EQUIPMENT DAMAGE DO NOT
CONNECT POWER SUPPLY
DIRECTLY TO ELEMENTS.
Connecting power directly to the
elements will result in a dry fire
and result in elevated tempera-
tures and a fire hazard.
MX4E-6E
A
B
C
D
E
F
G
H
I
J
K
L
M
NOTES :
1. M= Optional AutoFlush.
Dimension includes 3
1
⁄2 inch
nipple (not supplied )
2. All units in inches (MM)
9
3
⁄4 (248)
11 (280)
16
1
⁄2 (419)
20
3
⁄4 (527)
1
3
⁄8 (34)
2
3
⁄8 (60)
5
7
⁄8 (150)
5
7
⁄8 (150)
7
7
⁄8 (200)
1
7
⁄8 (48)
25
1
⁄8 (638)
2
3
⁄8 (60)
6
3
⁄8 (162)
