9.15 Voltage regulation
All of the parameters required for voltage regulation are described in this
section.
Settings
Parameters
Voltage re...ion
Name Value
Desired value 1 100V
Desired value 2 100V
Desired value 3 100V
Selecting a desired value Desired value 1
Bandwidth 1.0%
Delay time T1 40s
Time response T1 Linear
Activate delay time T2 Off
Delay time T2 10s
Home
Events
Information
Recorder
Settings
EN
CHANGE
REBOOT
admin 23.09.2020 09:23
Figure104: Voltage regulation (example)
1. Go to Settings > Parameters > On-load tap-changer regulator > Volt-
age regulation.
2. Select the desired parameter.
3. Set the desired parameter.
4. Press the Accept button to save the modified parameter.
9.15.1 Setting the desired value
In accordance with the order, the device is equipped with one of the follow-
ing variants for setting the desired value:
9.15.1.1 Desired value 1
1. Go to Settings > Parameters > Grid > Control > Desired value.
2. Enter the desired value.
3. Press the Accept button to save the modified parameter.
9.15.1.2 Desired value 1...3
You can set 3 different desired values. The device always uses one of the
set desired values for control. You can define the desired value used for
control by means of the "Select desired value" parameter or with the digital
inputs.
