MR MESSKO MT-ST Compact RM User Manual

5 Installation and commissioning
59BA5831400-00 EN
3. Connect the wires at the free end of the connection cable in the control
cabinet in accordance with the supplied connection diagram.
Figure43: Connection assignment, view of installed ANSI connector
1 Black 2 Red
3 Blue 4 Orange
5 Yellow 6 Brown
7 Red/black 8 Blue/black
9 Orange/black
5.4.7 Connecting the analog sensor (optional/TT version)
The pointer thermometer is equipped with a passive sensor that converts the
temperature value into a 4…20mA electrical signal. The sensor has a 2-
conductor design.
