INTERSECTOR Microwave Motion and
Presence Sensor Installation Instructions
MS Sedco INTERSECTOR Installation Instructions Page 19 INTERSECTOR-1.9Uv092717
ADJUSTMENTS (continued)
OPERATIONAL MODE:
Unplug the Laptop Ethernet cable from the Laptop Ethernet Port. Move the Sensor
Ethernet cable to the Operational Ethernet port. The green LED indicating connection
and the yellow LED indicating data should be on. The 2 or 4 LED for outputs will turn
off when a valid connection has been established to the sensor. Confirm operation of
each zone. Ensure that the appropriate LED light up when detection occurs.
Software versions 1.9S and newer include features that were not available in earlier
versions. These include:
• Ability to configure up to 8 outputs using two (2) TCIB connected as Primary and
Secondary units.
• Ability to remove zones from crosswalk area to avoid pedestrian detection.
• Ability to enable Collision Avoidance feature for zones in potentially dangerous
areas.
• Ability to detect vehicles traveling in the wrong direction through zones.
DEFINITIONS:
OUTPUT UPGRADE:
Allows the configuration of up to 8 outputs using both a Primary and Secondary TCIB.
TAIL EXTENSIONS:
Allows the end user to remove the zone from the crosswalk to avoid pedestrian
detection that might cause a false call.
WRONG WAY DETECTION (DEPARTING TRAFFIC DETECTION):
Enables the detection of vehicles traveling in the wrong direction in a lane, or entering
on/off ramps. This option can be also used to detect traffic in departing lanes.
COLLISION AVOIDANCE/ SPEED BINS:
The Collision Avoidance feature, based on a new direction from the FHWA, allows the
user to set up zones with speed values. In the event a vehicle exceeds that speed while
in the zone an output is provided to the controller to extend the Collision Avoidance
system. These Speed Bins can then be set up to activate an advanced warning system
as vehicles are approaching dangerous curves or work zones at excessive speeds.
