INTERSECTOR1.9U SOFTWARE ADDENDUM
INTERSECTOR Microwave Motion and
Presence Sensor Installation Instructions
MS Sedco INTERSECTOR Installation Instructions Page Addendum-1 INTERSECTOR-1.9Uv092717
This addendum details changes to the INTERSECTOR features that are dependent on
the following conditions:
• TC-CK1-SBE main board
software is upgraded to
1.9U
• Radar firmware upgraded to
229-05-8
• TCIB software upgraded to
1.4S
TC-CK1-SBE 1.9U UPDATES
There are five key features that change in the 1.9U software:
1. Rain Failsafe
2. Automated OZP
3. Zone Clear Feature
4. Save and Load Zone Data
5. Bicycle Classification Sensitivity
EXPLANATION OF CHANGES
Rain Failsafe
The 1.9U version of
INTERSECTOR software
calculates a Rain Intensity Factor
by counting the number of
raindrops detected within the
first 10 feet of the radar’s view
and measuring the size of the
drops. The Rain Intensity Factor
and Rain Flag are displayed on
the Zone Settings page above
the grid. As shown in Figure 1,
Rain Intensity Factor is the first
number.
Figure 1
