MSA FireHawk M7 - Page 2

2
TAL 114 (L) Rev. 7 - 10093086
FIREHAWK M7 SECOND STAGE REGULATOR
Firehawk M7 Second Stage Regulator Replacement and Overhaul Kits
Item PN Description
1
10047441 Cover, Purge ••••
10047664 Cover, Non Purge ••••
2 10018622 Retainer, Spring (not req’d w/ Solid Cover) ••••
3 10092041 Spring, Diaphragm ••••••••
4 10047528 Cap, Spring ••••••••
5 10044026 Shield, CBRN ••••••••
6 10039172 Diaphragm, CBRN ••••••••
7 10087295 Valve Assembly ••••••••
8 10047238 Button, Push to-Connect ••••••••
9 10023509 O-Ring (2 Required) ••••••••
10 10037951 O-Ring (2 Required) ••••••••
11 10018965 Spring, Button ••••••••
12 697453 O-Ring, Silicone, Red ••••••••
13 10018971 Bypass Insert ••••••••
14 10018774 Knob, Bypass ••••••••
15 634669 O-Ring ••••••••
16 10018547 U-Clip (2 Required) ••••••••
17 10018966 Body, Bypass ••••••••
18 10020784 Screen, Bypass ••••••••
19 10039171 Hose, Threaded •• ••
19a 10046484 Hose, Quick-Connect • •••
20 10087301 Housing Assembly ••••••••
21 10031192 Seal Ring ••••••••
22 10047331 Button, Slide-to-Connect •• • •
604070 Christo-Lube Lubricant ••••••••
10043892 10043893 10043894 10043895 10047529 10047600 10047601 10047602
Parts List
P/N Description
Firehawk M7 Second Stage Regulator Replacement Kits
10087305
10087295 Valve Assembly
10087301 Housing Assembly
10087295 Valve Assembly
10087301 Housing Assembly
Firehawk M7 Second Stage Regulator Overhaul Kits
10023509 O-Ring (2)
10037951 O-Ring (2)
697453 O-Ring, Silicone, Red
634669 O-Ring (2)
63198 O-Ring
10048942 10020784 Screen
10047528 Cap, Spring
10044026 Shield, CBRN
10031192 Ring, Seal
10039172 Diaphragm Assy.
809028 Lubricant, Christo-Lube
10091435
10047528 Cap, Spring
10044026 Shield, CBRN
10091436 10031192 Seal Ring (Pack of 10)
10091437 10023509 O-Ring (Pack of 10)
10091438 10037951 O-Ring (Pack of 10)
10091439 10018965 Spring, Button (Pack of 10)
10091440 697453 O-Ring, Silicone, Red (Pack of 10)
10091461 634669 O-Ring (Pack of 10)
10100035 10092041 Spring, CBRN (Pack of 28)
10100036 10020931 Spring, PD (Pack of 28)
Height Gauge Kits
10090457 10090457 Height Gauge for PN 10087295 w/ instructions
10050211 10050146 Height Gauge for PN 10030664 w/ instructions
Regulator Assembly
