enter an output number to configure. Once entered the other features on this screen now apply to this
output number. For a small amount of configuration this selection method is most direct.
"Step Output # to Configure" - This is a push button which steps the output number from its current
value up to 32 and back to 1 again in a loop. When a large amount of configuration is needed this
button allows easy sequential stepping through all of the outputs.
"UCO#2 is NOT Available" - This is an indicator that shows UCO option #2 has not been MSA
factory configured. If UCO option #2 was configured the indicator will read "UCO#2 is Available".
"On-Delay" - This numerical entry element represents an on-delay in the range 0-180 seconds for the
specified output. By default no on-delay exists (0 seconds).
"Off-Delay" - This numerical entry element represents an off-delay in the range 0-180 seconds for
the specified output. By default no off-delay exists (0 seconds). Ten seconds are shown above.
"Non-Fail-Safe" - This push button selects "Fail-Safe" (normally energized) or "Non-Fail-Safe"
(normally de-energized) mode of operation for the specified output. By default Non-Fail-Safe
operation is set.
"Steady" - This push button selects "Steady" or "Pulsed" operation of the selected output. By default
steady operation is set. The pulsed output is 50% duty cycle (1 second on and 1 second off).
"Not ACK" - This push button selects either acknowledge on or off for the specified output.
"UCO ENAB" - This is an HMI navigation button that changes the screen to the UCO Enable screen
which allows the selection of which points trigger the outputs.
"GOTO UCO Option #2" - This push button allows the operator to select which of the two UCO
options is to be configured. It can also read "GOTO UCO Option #1". Note that the screen title
changes is response to this switch and is always opposite.
"System Menu" - An HMI navigation button which switches the screen back to the System Setup
Menu.
