A-13

Using 2-, 4- & 6-Channel Audio Function

1 * Line Out (Rear channels)

2 Line Out (Front channels)

3 * Line Out (Center and Subwoofer channel)

4 SPDIF Coaxial jack

* Both Line In and MIC

function are converted to Line

Out function when 6-Channel

Mode for 6-Speaker Output is

selected.

 6-Channel Mode for 6-Speaker Output

Refer to the following diagram and caption for the function of each

jack on the back panel when 6-Channel Mode is selected.

MSI Reminds You...

If the audio signals coming from the Center and Subwoofer

speaker are swapped when you play video or music on the

computer, a converter may be required to exchange center and

subwoofer audio signals. The converter can be purchased from

a speaker store.

Back Panel
