MSI B360M ICAFE User Manual

3
Safety Information Specifications
Specifications
CPU
Supports 8th Gen Intel
®
Core™, Pentium
®
Gold and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
B360 Chipset
Memory
y 2x DDR4 memory slots, support up to 32GB
y Supports DDR4 2666/ 2400/ 2133 MHz
y Supports Dual-Channel mode
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on
compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot
y 2x PCIe 3.0 x1 slots
Onboard
Graphics
y 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz (B360M PRO-VD, B360M ICAFE)
y 1x HDMI™ port 1.4, supports a maximum resolution of
4096x2160@30Hz (B360M PRO-VH, B360M FIRE)
Storage
Intel
®
B360 Chipset
y 6x SATA 6Gb/s ports
y 1x M.2 slot (Key M)
 Supports up to PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
 Intel
®
Optane™ Memory Ready*
* Before using Intel
®
Optane™ memory modules, please
ensure that you have updated the drivers and BIOS to the
latest version from MSI website.
USB
Intel
®
B360 Chipset
y 6x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports
on the back panel, 2 ports available through the internal USB
connector)
y 6x USB 2.0 (High-speed USB) ports (2 ports on the back
panel, 4 ports available through the internal USB connectors)
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
Continued on next page

MSI B360M ICAFE Specifications

General

Chipset	Intel B360
Form Factor	Micro-ATX
CPU Socket	LGA 1151
Maximum Memory	64 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
Audio	Realtek ALC887
Memory Slots	4
Storage Interface	6 x SATA 6Gb/s, 1 x M.2
LAN	Realtek RTL8111H
