Rear I/O Panel
Rear I/O Panel
PS/2 Keyboard/Mouse
PS/2 Keyboard/Mouse
PS/2 Keyboard/Mouse
B360M PRO-VH, B360M FIRE
B360M WIND
B360M PRO-VD, B360M ICAFE
LAN
LAN
LAN
Line-in
Line-in
Line-in
Mic in
Mic in
Mic in
Line-out
Line-out
Line-out
USB 3.1 Gen1 (5Gbps)
USB 3.1 Gen1 (5Gbps)
USB 3.1 Gen1 (5Gbps)
VGA
VGA
VGA
DVI-D
USB 2.0
USB 2.0
USB 2.0
