JFP1, JFP2: Front Panel Connectors
These connectors connect to the front panel swtches and LEDs. The JFP1 connector s
complant wth the Intel
®
Front Panel I/O Connectvty Desgn Gude. When nstallng the
front panel connectors, please use the enclosed mConnectors to smplfy nstallaton.
Plug all the wres from the computer case nto the mConnectors and then plug the
mConnectors nto the manboard.
1.+
3.-
10.NoPin
5.-
ResetSwitch
HDDLED
PowerSwitch
PowerLED
7.+
9.Reserved
8.-
6.+
4.-
2.+
JFP1
1.Ground
3.SuspendLED
5.PowerLED
7.NoPin
8.+
6.-
4.+
2.-
Buzzer
Speaker
JFP2
Important
On the connectors comng from the case, pns marked by small trangles are postve
wres. Please use the dagrams above and the wrtng on the mConnectors to
determne correct connector orentaton and placement.
The majorty of the computer cases front panel connectors wll prmarly be plugged
nto JFP1.


