En-23
Englsh
JAUD1: Front Panel Audo Connector
Ths connector allows you to connect the front audo panel located on your computer
case. Ths connector s complant wth the Intel
®
Front Panel I/O Connectvty Desgn
Gude.
1
MICL
3.MICR
10.HeadPhoneDetection
5.HeadPhoneR
7.SENSE_SEND
9.HeadPhoneL
8.NoPin
6.MICDetection
4.NC
2.Ground
JTPM1: TPM Module Connector
Ths connector connects to a TPM (Trusted Platform Module). Please refer to the TPM
securty platform manual for more detals and usages.
* The MB layout n ths 󰘰gure s for reference only.
0.NoPin
14.Ground
8.5VPower
12.Ground
6.SerialIRQ
4.3.3VPower
2.3VStandbypower
1.LPC
Clock
3.LPC
Reset
5.LPCaddress&
d
atapin0
7.LPC
address&
d
ata
pin1
9.LPC
address&
d
ata
pin2
11.LPC
a
ddress
&d
ata
p
in3
13.LPC
F
rame
TPM module s optonal
