JUSB3: USB 3.0 Expanson Connector
The USB 3.0 port s backwards compatble wth USB 2.0 devces. It supports data
transfer rates up to 5Gbts/s (SuperSpeed).
115V
5.
USB3_TX_C_DN
4
.Ground
3
.USB3_RX_DP
2.USB3_RX_DN
1.Power
10.Ground
9. +U
SB2.0
8
.
-
U
SB2.0
7.Ground
6.U
SB3_TX_C_DP
20.No Pin
19.Power
18.USB3_RX_DN
17.USB3_RX_DP
16.Ground
15.USB3_TX_C_DN
14.USB3_TX_C_DP
13.Ground
12.USB2.
0
-
11
. +
US
B
2.
0
* The MB layout n ths 󰘰gure s for reference only.
USB 3.0 Bracket (optonal)
Important
Note that the VCC and GND pns must be connected correctly to avod possble
damage.
To use a USB 3.0 devce, you must connect the devce to a USB 3.0 port through an
optonal USB 3.0 complant cable.


