DRAM Tmng Mode
Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect)
EEPROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the
followng Advanced DRAM Conguraton sub-menu to be determned by BIOS based
on the conguratons on the SPD. Selectng [Lnk] or [Unlnk] allows users to congure
the DRAM tmngs for each channel and the followng related Advanced DRAM
Conguraton sub-menu manually.
Advanced DRAM Conguraton
Press <Enter> to enter the sub-menu.
Command Rate
Ths settng controls the DRAM command rate.
tCL
Controls CAS latency whch determnes the tmng delay (n clock cycles) of startng
a read command after recevng data.
tRCD
Determnes the tmng of the transton from RAS (row address strobe) to CAS
(column address strobe). The less clock cycles, the faster the DRAM performance.
tRP
Controls number of cycles for RAS (row address strobe) to be allowed to pre-charge.
If nsucent tme s allowed for RAS to accumulate before DRAM refresh, the DRAM
may fal to retan data. Ths tem apples only when synchronous DRAM s nstalled
n the system.
tRAS
Determnes the tme RAS (row address strobe) takes to read from and wrte to
memory cell.
tRFC
Ths settng determnes the tme RFC takes to read from and wrte to a memory
cell.
tWR
Determnes mnmum tme nterval between end of wrte data burst and the start of a
pre-charge command. Allows sense amplers to restore data to cell.
tWTR
Determnes mnmum tme nterval between the end of wrte data burst and the start
of a column-read command; allows I/O gatng to overdrve sense amples before
read command starts.
tRRD
Speces the actve-to-actve delay of derent banks.
tRTP
Tme nterval between a read and a precharge command.
