FX5700-VT2DR256/VT2DR128
Layout
nVIDIA GeForce FX GPU
256MB/128MB DDR RAM
Flash-BIOS
AGP Interface
Fan Connector
Video Decoder
1
st
DVI-I Connector
TV_Out / Video_In Connector
(S&C)
2
nd
DVI-I Connector
MSI reminds you...
To connect dual monitors, please follow the steps listed below :
1. Attach the supplied DVI-I / VGA Adapter to the first DVI con-
nector of the VGA card, and then connect the first monitor to
it.
2. Now, connect the second monitor to the TV_Out / Video_In
Connector or the second
DVI connector.
