Chapter 3
3-8
The VGA card provides a Video_In connector for video-in function which al-
lows you to input the image from video devices. Simply plug one end of the
S_Video cable into the Video_In connector on the VGA card, and the other
end to the video output connector on your video devices. Some video devices
may support such kind of output connector. For the correct connection, please
refer to the video devices' manuals for more information.
3.7 Video_In Connector (S)
3.6 Video_In Connector (C)
The VGA card provides a Video _In connector for video-in function which
allows you to input the image from video devices. Simply plug one end of the
RCA cable into the Video_In connector on the VGA card, and the other end to
the video output connector on your video devices. Most video devices support
such kind of output connector. For the correct connection, please refer to the
video devices' manuals for more information.
Video_In
Connector (C)
Video_In
Connector (S)
DVD/VCD
player
Video player
Video camera
Digital camera
DVD/VCD
player
Video player
Video camera
To Next Page
