MSI H67MS-E23 B3 series User Manual

MS-7680 Mainboard
English
En-3
MS-7680 Mainboard
English
* If you need to purchase accessories and request the part numbers, you could search
the product web page and 󰘰nd details on our web address http://www.msi.com/index.
php
Connectors
Back panel
1 PS/2 keyboard/ mouse combo port
2 USB 3.0 ports (H67MA-E35 (B3))
4 USB 2.0 ports
1 HDMI port* (H67MA-E35 (B3))
1 VGA port*
1 DVI-D port*
1 LAN port
6 󰘱exible audio ports (H67MA-E35 (B3)) /
3 󰘱exible audio ports (H67MS-E23 (B3))
*(The HDMI, DVI-D and VGA ports only work with Integrated Graphics Processor)
On-Board
3 USB 2.0 connectors
1 Chassis Intrusion connector
1 S/PDIF-Out connector
1 Front Panel Audio connector
1 TPM Module connector
1 Parallel port connector
1 Serial port connector
Slots
1 PCIE x16 slot
2 PCIE x1 slots
1 PCI slot
Form Factor
Micro-ATX (24.5 cm X 21.5 cm)
Mounting
6 mounting holes
■
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
■
■
■
■
■

MSI H67MS-E23 B3 series Specifications

General

Brand	MSI
Model	H67MS-E23 B3 series
Category	Motherboard
Language	English
