MSI MS-6567 User Manual

Chapter 1
1-2
CPU
* Supports Socket 478 for P4 processors (Willimate 478 and Northwood 478)
* FSB @ 400/533 MHz (100/133 MHz QDR)
* Supports 1.3GHz, 1.4GHz, ... 2.4GHz and up
Chipset
* SiS 645DX chipset (702 BGA)
- Supports 64-bit P4 processors at 533MHz
- Supports 32-bit AGP 4x/2x slot
- Supports 64-bit high performance DDR333 / DDR266 memory controller
- Supports bi-directional 16-bit data bus with 533MHz bandwidth MuTIOL
* SiS 961B chipset (371 BGA)
- Supports Dual-IDE ATA 66/100/133
- AC’97 link controller
- Low pin count interface for SIO
Main Memory
* Three 184-pin DDR DIMM sockets
* Maximum memory size up to 3GB without ECC
Slots
* One AGP (2x/4x) universal slot
* Five 32-bit Master PCI slots (PCI v2.2)
* One CNR (Communication Network Riser) slot
On-Board IDE
* Dual IDE controllers integrated in SiS 961B
* Supports PIO, Bus Master, Ultra DMA 66/100/133 operation
* Can connect up to 4 IDE devices
On-Board Peripherals
External:
- PS2 Keyboard + PS2 Mouse
- USB x 2
- Parallel + Serial 2
- Game port + Audio (Mic-in, Line-in, Line-out)
- RJ45 (LAN)
Internal:
- Front Panel (2 x 5) w/ Intel pin definition
- Front USB (2 x 5) w/ Intel pin definition * 2
- Front Audio (2 x 5) w/ Intel pin definition
Mainboard Specification

MSI MS-6567 Specifications

General

Model	MS-6567
Form Factor	ATX
Socket Type	Socket 478
Memory Type	DDR SDRAM
Max Memory	2 GB
AGP	1 x AGP 4x
Onboard Audio	Yes
Audio	AC'97
Onboard LAN	Yes
LAN	10/100 Mbps
Supported CPUs	Intel Pentium 4
Memory Slots	2
Storage Interfaces	2 x IDE
USB Ports	4
Chipset	Intel 845
