1-3
Getting Started
RAID
- 4 SATA ports support RAID 0/ 1/ 0+1/ 5 or JBOD mode
- 2 eSATA ports (back panel) support RAID 0/ 1 mode
Floppy
- 1 floppy port
- Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 IEEE 1394 port (optional)
- 1 Optical SPDIF-Out port
- 2 eSATA ports
- 1 Clear CMOS button
- 4 USB 2.0 ports
- 1 LAN jack
- 6 flexible audio jacks
On-Board Pinheaders
- 1 Chassis Intrusion pinheader
- 2 USB 2.0 pinheaders
- 1 IEEE 1394 pinheader (optional)
- 1 SPDIF-out pinheader
- 1 CD-in connector
- 1 front panel audio pinheader
- 1 TPM Module pinheader (optional)
- 1 COM Port pinheader (optional)
Slots
- 3 PCI Express x16 slots
a. the mazarine PCI Express x 16 slot (PCI_E1) supports up to PCI
Express 2.0 x16
b. two blue PCI Express x16 slots, each one supports up to
PCIE 2.0 x8
c. supports SLI technology
- 2 PCI slots, support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.4 cm X 24.5 cm)
Mounting
- 9 mounting holes
