3-13
BIOS Setup
On-Chip ATA Devices
Press <Enter> to enter the sub-menu and the following screen appears:
PCI IDE BusMaster
This item allows you to enable/ disable BIOS to use PCI busmastering for read-
ing/ writing to IDE drives.
On-Chip SATA Controller
This item allows users to enable or disable the SATA controller.
RAID mode
This item allows you to configure SATA mode. Setting options: [RAID],[AHCI] or
[IDE].
I/O Devices
Press <Enter> to enter the sub-menu and the following screen appears:
COM Port 1
Select an address and corresponding interrupt for the first serial port.
Parallel Port
There is a built-in parallel port on the on-board Super I/O chipset that provides Standard,
ECP, and EPP features. It has the following options:
[Disabled]
[3BC/IRQ7] Line Printer port 0
[278/IRQ5] Line Printer port 2
[378/IRQ7] Line Printer port 1
