3-22
MS-7530 Mainboard
1.If you do not have any EMI problem, leave the setting at [Disabled] for
optimal system stability and performance. But if you are plagued by EMI,
select the value of Spread Spectrum for EMI reduction.
2.The greater the Spread Spectrum value is, the greater the EMI is reduced,
and the system will become less stable. For the most suitable Spread
Spectrum value, please consult your local EMI regulation.
3.Remember to disable Spread Spectrum if you are overclocking because
even a slight jitter can introduce a temporary boost in clock speed which
may just cause your overclocked processor to lock up.
Important
DRAM Voltage (V)
Adjusting the memory voltage can increase the memory speed.
NB Voltage (V)
Adjust the North Bridge chipset voltage.
VTT FSB Voltage (V)
This item allows you to set the FSB VTT voltage.
CPU/LDT Spread Spectrum
This setting is used to enable or disable the CPU Spread Spectrum feature. When
overclocking the CPU, always set it to [Disabled].
iGPU Spread Spectrum
This setting is used to set the internal GPU spread spectrum. When overclocking,
please set it lower.
SATA Spread Spectrum
This setting is used to enable or disable the SATA Spread Spectrum feature. When
overclocking, always set it to [Disabled].
