MSI MS-99A1 - Page 11

1-3
Overview MS-99A1
Rear Panel I/O
■ 2 x RS232/422/485 Serial Ports
■ 1 x HDMI Port
■ 1 x DisplayPort
■ 6 x Gigabit LAN Jacks
■ 2 x USB 3.0 Ports
■ 2 x USB 2.0 Ports
Expansion Slots
■ 1 x MXM Slot
■ 1 x PCIe x1 Slot
■ 2 x Mini-PCIe Slots
- MINI_PCIE1 supports full-size mSATA, WiFi and Bluetooth modules with
USB 2.0 signal.
- MINI_PCIE2 supports full-size WiFi/Bluetooth/3G modules with USB 2.0
signal. (Optional by SKU)
■ 1 x SIM Card Slot (Optional by SKU)
Form Factor
■ Mini-ITX: 170mm x 170mm
Environmental
■ Operating Temperature: -10 ~ 60
o
C
■ Storage Temperature: -20 ~ 80
o
C
■ Humidity: 10 ~ 90% RH, non-condensing
Regulatory Compliance
■ EMC: CE, FCC, BSMI, RCM, VCCI
■ RoHS compliant
