MSI MS-99A1 - Board Specifications

1-2
Overview MS-99A1
Board Specications
Storage
■ 1 x SATA 6Gb/s Port
■ 1 x SD Card Slot
Network
■ LAN1: Based on CPU Module Board
■ LAN2 ~ LAN6: Intel I211-AT GbE LAN
Audio
■ Realtek ALC887 Audio Codec
■ 1 x Front Audio Connector
■ 1 x Amplier Connector
Graphics
■ HDMI, DisplayPort, LVDS Interfaces
Onboard Headers/ Connectors/ Jumpers
■ 1 x 4-pin DC Power Connector
■ 1 x 4-pin SATA Power Connector
■ 1 x System FAN Connector
■ 1 x CPU FAN Connector
■ 1 x SATA 6Gb/s Port
■ 1 x Front Panel Connector
■ 1 x Front Audio Connector
■ 1 x Amplier Connector
■ 4 x RS232 Serial Port Connectors
■ 1 x UART Connector
■ 1 x GPIO Connector
■ 1 x SMBus Connector
■ 1 x CAN Bus Connector (Depending on CPU Module Board)
■ 1 x USB 2.0 Connector (1 port)
■ 1 x LVDS Connector
■ 1 x Inverter Connector
■ 1 x Keyboard/Mouse Connector
■ 1 x Chassis Intrusion Header
■ 1 x BIOS Select Jumper
■ 1 x Inverter Power Jumper
■ 1 x LVDS Power Jumper
■ 1 x I2C Power Jumper
■ 1 x AT/ATX Select Jumper
■ 3 x COM Port Power Jumpers
■ 5 x LAN NVM Jumpers
