1-3
Getting Started
USB Interface
† 8 USB ports
- 4 ports in the rear I/O, 4 ports via the external bracket
LAN
† Realtek
®
8100C (10/100 Mb/s) or 8110S (10/100/1000 Mb/s) chip
- Integrated Fast Ethernet MAC and PHY in one chip
- Supports 10Mb/s, 100Mb/s and the 8110S supports up to 1000Mb/s
- Compliance with PCI v2.2
- Supports ACPI Power Management
IEEE 1394 (Optional)
† VIA
®
6307 IEEE 1394 controller
- Supports up to two 1394 ports (rear panel x 1, pinheader x 1).
- Transfer rate is up to 400Mbps
Audio
† AC97 link controller integrated in ATi SB400.
† 6 channels S/W audio codec Realtek ALC655 codec
- Compliance with AC97 2.3 Spec
- Meets PC2001 audio performance requirement
On-Board Peripherals
† On-Board Peripherals include:
- 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 2 serial port (rear*1/ front*1)
- 1 VGA port
- 1 parallel port supporting SPP/EPP/ECP mode
- 8 USB2.0 ports (Rear*4/Front*4)
MSI Reminds You...
1.Please note that users cannot install OS, either WinME or Win98,
in their SATA hard drives. Under these two OSs, SATA can only be
used as an ordinary storage device.
2.To create a bootable RAID volume for a Windows 2000 environment,
Microsoft’s Windows 2000 Service Pack 4 (SP4) is required. As
the end user cannot boot without SP4, a combination installation
CD must be created before attempting to install the operating sys-
tem onto the bootable RAID volume.
To create the combination installation CD, please refer to the fol-
lowing website:
http://www.microsoft.com/windows2000/downloads/
servicepacks/sp4/HFdeploy.htm
