MSI Z790 EDGE WIFI

18
Continued from previous column
LED Features
 1x 4-pin RGB LED connector
 3x 3-pin ARGB Gen2 LED connectors
 4x EZ Debug LED
 1x LED Demo connector
Back Panel
Connectors
 1x DisplayPort
 1x HDMI™ port
 1x Clear CMOS button
 1x Flash BIOS button
 4x USB 3.2 Gen 1 5Gbps Type-A ports (From Hub GL3523)
 4x USB 3.2 Gen 2 10Gbps Type-A ports (From Z790
chipset)
 1x USB 3.2 Gen 2 10Gbps Type-C port (From Z790 chipset)
 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From Z790
chipset)
 1x 2.5Gbps LAN (RJ45) port
 2x Wi-Fi antenna connectors
 5x Audio jacks
 1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
 CPU/ System/ Chipset temperature detection
 CPU/ System/ Pump fan speed detection
 CPU/ System/ Pump fan speed control
Form Factor
 ATX Form Factor
 9.6 in. x 12 in. (244 mm x 305 mm)
BIOS Features
 1x 256 Mb flash
 UEFI AMI BIOS
 ACPI 6.4, SMBIOS 3.5
 Multi-language
Continued on next column
