MTD 1033 User Manual

English Operating manual
8
 Insert retaining bar (6) through
the openings (3, 4, 5) in order
to secure the gearbox.
 While holding the retaining bar (6),
attach the cutting blade (7) with
blade holder (8), retaining bell (9)
and nut (10) as follows:
– Push cutting blade (7) onto
drive shaft (2) and centre on
the spacer (1).
Note
Ensure that the cutting blade (7) is
seated correctly on the spacer (1),
i.e. centred and resting flat!
– Attach blade holder (8),
retaining bell (9) and nut (10).
Ensure that the blade holder is
seated correctly in the toothing!
– Tighten nut firmly anti-clockwise
(to the left) – tightening torque
37 Nm.
Note
–
Before tightening, check again that
the cutting blade is seated correctly.
– If you do not have a torque wrench,
tighten the nut firmly by hand.
Then tighten the nut anti-clockwise
(to the left) another half turn using
a ring spanner.
 Remove retaining bar from the
gear head.
 Remove guard (if fitted) from
the cutting blade.
Removing the cutting blade
Fig. 8
 Attach guard (if available) to the
cutting blade.
 Align the openings (3, 4, 5).
Insert retaining bar (6) through the
openings and hold in position.
 Unscrew nut clockwise (to the right).
 Remove cutting blade (7), blade
holder (8) and retaining bell (9)
(Fig. 7).
Oil and petrol
Oil
Use quality oil only, API classification
TC (TSC-3) which is offered for air-
cooled two-stroke engines.
Mix the oil for two-stroke engines
according to the instructions on
the container, 1:40 (2.5 %).
Petrol
a~åÖÉê=
råÇÉê=ÅÉêí~áå=ÅçåÇáíáçåë=éÉíêçä=áë=
ÉñíêÉãÉäó=Ñä~ãã~ÄäÉ=~åÇ=ÉñéäçëáîÉK
Ó oÉÑìÉä=çåäó=áå=~=ïÉää=îÉåíáä~íÉÇ=~êÉ~=
~åÇ=ïáíÜ=íÜÉ=ÉåÖáåÉ=ëïáíÅÜÉÇ=çÑÑK=
aç=åçí=ëãçâÉ=~åÇ=ëïáíÅÜ=çÑÑ=~ää=
áÖåáíáçå=ëçìêÅÉë=áå=íÜÉ=îáÅáåáíó=çÑ=íÜÉ=
í~åâ=çê=~í=íÜÉ=ÑìÉä=ëíçê~ÖÉ=ÇÉéçíK
Ó aç=åçí=çîÉêÑáää=íÜÉ=ÑìÉä=í~åâ=EíÜÉêÉ=
ãìëí=ÄÉ=åç=ÑìÉä=áå=íÜÉ=áåäÉí=åçòòäÉFK=
^ÑíÉê=ÑáääáåÖ=ìé=íÜÉ=éÉíêçä=í~åâI=
ÉåëìêÉ=íÜ~í=íÜÉ=í~åâ=Å~é=áë=ÅäçëÉÇ=
~åÇ=ëÉÅìêÉÇK
Ó tÜÉå=ÑáääáåÖ=ìé=íÜÉ=éÉíêçä=í~åâI=Çç=
åçí=ëéáää=~åó=ÑìÉäK=péáääÉÇ=ÑìÉä=çê=
éÉíêçä=î~éçìêë=ã~ó=áÖåáíÉK=fÑ=ÑìÉä=
Ü~ë=ÄÉÉå=ëéáääÉÇI=ÉåëìêÉ=íÜ~í=íÜÉ=
~êÉ~=áë=ÇêáÉÇ=ÄÉÑçêÉ=íÜÉ=ÉåÖáåÉ=áë=
êÉëí~êíÉÇK
Ó mêÉîÉåí=êÉéÉ~íÉÇ=çê=éêçäçåÖÉÇ=
ëâáå=Åçåí~Åí=çê=áåÜ~ä~íáçå=çÑ=íÜÉ=
î~éçìêëK
`~ìíáçå
aç=åçí=Ñáää=ìé=ïáíÜ=ÑìÉä=çÑ=ëéÉÅáÑáÅ~íáçå=
bURK=fÑ=ÑìÉä=çÑ=ëéÉÅáÑáÅ~íáçå=bUR=
EÉíÜ~åçä=ÅçåíÉåí=[NR=BF=áë=ìëÉÇI=íÜÉ=
ÉåÖáåÉ=ã~ó=ÄÉ=Ç~ã~ÖÉÇK=
qÜÉ=ìëÉ=çÑ=~å=ìå~ìíÜçêáëÉÇ=ÑìÉä=ïáää=
îçáÇ=íÜÉ=ï~êê~åíóK=
See instructions on mixing
oil and petrol
Age and/or incorrectly mixed fuel are
the main reasons for the unit not
running properly.
Always use clean, fresh unleaded
petrol (no more than 60 days old,
minimum octane number 91 ROZ).
Follow exactly the instructions for
the correct petrol/oil mixture.
Correctly mix two-stroke engine oil
and lead-free petrol, 1:40 (2.5 %).
Do not mix directly in the tank.
Fill the tank with petrol.
Fig. 1
 Remove tank cap (4).
 Fill fuel tank with petrol/oil mixture.
Never overfill!
 Close fuel tank tightly.
 Move the unit approx. 10 m from
the filling station/fuel container
before starting the engine.
Operation
a~åÖÉê=
aç=åçí=Üççâ=íÜÉ=ëÜçìäÇÉê=ëíê~é=çåíç=
íÜÉ=ìåáí=ìåíáä=íÜÉ=ÉåÖáåÉ=Ü~ë=ëí~êíÉÇK
 Mix petrol (gasoline) with oil.
Fill the tank with the mixture.
See „Oil and petrol“.
Starting the engine
Starting the cold engine.
Fig. 9
 Press throttle lock (2) and press
the throttle (3) all the way and hold
in position.
 Move the ignition switch (1) to
the START position.
 Release throttle lock and throttle.
Note
Both levers remain locked in the
depressed position (cold start
position).
 Slowly and fully press intake
pump/primer (5) 6x (Fig. 10).
The fuel must be visible in the
pump. If this is not the case,
keep pressing until fuel is visible.
 Move choke lever (6) to position
1/ (Fig. 11).
 Press the unit on the ground.
 Slowly pull on the starter cable (7)
until it begins to resist. Then pull
quickly and forcefully until the
engine starts (Fig. 12).
After starting the engine, do not let
the pull-starter spring back, but
slowly guide it back.
 Leave the engine running for
approx. 1–2 minutes.
 Move choke lever (6) to position
2/ and leave the engine to
warm up for another 1–2 minutes
(depending on the outside
temperature) (Fig. 11).
!
!
