AIR
FILTER
Under
normal
operating
conditions,
the
air
cleaner,
located
on
top
of
the
carburetor,
must
be
serviced
after
every
ten
hours
of
use.
Under
extremely
dusty
operating
conditions,
the
air
cleaner
must
be
serviced
after
every
hour
of
operation.
See
figure
28.
Step
1.
Remove
the
wing
nut
and
cover.
Step
2.
Remove
the
paper
element
from
the
support
base.
Step
3.
To
clean,
tap
the
paper
element
(either
top
or
bottom)
on
a
flat
surface
or
wash
in
a
non¬
sudsing
detergent
and
flush
from
the
inside
until
the
water
is
clear.
After
washing,
air
dry
thoroughly
before
using.
FIGURE
28A.
BRIGGS
&
STRATTON
AIR
FILTER
8
H.P.
AIR
FILTER
10
H.P.
ENGINE
Clean
and
re-oil
foam
pre-cleaner
at
3
month
intervals
or
every
25
hours,
whichever
occurs
first.
1.
Remove
wing
nut
and
cover.
2.
Remove
foam
pre-cleaner
element
by
sliding
it
up
off
of
the
paper
cartridge.
3
.
A—Wash
foam
in
liquid
detergent
and
water.
B—Squeeze
dry.
C—Oil
with
one
ounce
engine
oil.
Squeeze
to
dis¬
tribute
oil
evenly.
4.
Assemble
to
paper
cartridge.
Reassemble
cover
and
wing
nut.
Screw
wing
nut
down
tight.
FIGURE
28B.
BRIGGS
&
STRATTON
AIR
FILTER
10
H.P.
Yearly
or
every
TOO
hours,
whichever
occurs
first,
re¬
move
paper
cartridge.
Clean
by
tapping
gently
on
flat
surface.
If
very
dirty,
replace
cartridge,
or
wash
in
liquid
detergent
and
water.
Rinse
until
water
remains
clear.
Cartridge
must
be
air
dried
thoroughly
before
using.
NOTE:
Service
more
often
under
dusty
conditions.
CLUTCH-BRAKE
PEDAL
ADJUSTMENT
To
adjust
the
angle
of
the
clutch-brake
pedal,
remove
the
cotter
pin
and
washer
on
the
clutch
rod
and
turn
the
clutch
rod
in
or
out
of
the
ferrule
to
obtain
the
most
comfortable
angle
of
the
pedal
when
the
pedal
is
released.
Replace
the
washer
and
cotter
pin.
See
figure
30.
The
brake
adjustment
is
made
by
using
a
Vi"
deep
well
socket
and
turning
the
adjusting
nut
clockwise
through
the
opening
in
the
back
panel.
This
reduces
the
dis¬
tance
between
the
brake
band
and
the
drum.
See
fig¬
ure
29.
CAUTION
If
the
spring
tension
idler
goes
below
the
height
of
the
engine
pulley
when
the
clutch-brake
pedal
is
depressed
it
will
cause
excessive
belt
wear
and
the
brake
should
be
adjusted.
See
figure
30.
TRANSMISSION
BELT
REMOVAL
^
WARNING
^
Remove
spark
plug
lead.
Step
1
Remove
the
deck
belt
from
the
engine
pulley
in
reverse
order
as
described
in
the
assembly
portion
of
this
manual.
See
figures
10
through
15.
Step
2.
Remove
the
hex
bolt
from
the
spring
tension
idler.
13
