Set-Up
3
6
Gas & Oil
NOTE: The engine is shipped without gasoline or oil in the
engine. Running the engine with insufficient oil can cause
serious engine damage and void the engine warranty.
WARNING! Always keep hands and feet clear of
equipment moving parts. Do not use a pressurized
starting fluid. Vapors are flammable.
Oil Recommendations
Do not over-fill. Use a synthetic or non-synthetic 4-stroke, or an
equivalent high detergent, premium quality motor oil certified to
meet or exceed U.S. automobile manufacturer’s requirements for
this designation on the container.
SAE 10W-30 is recommended for general, all temperature use. If
single viscosity oil is used, select the appropriate viscosity for the
average temperature in your area from the chart below.
-30º -20º
10w
20w
20
30
40
20w40, 20w50
15w40, 15w50
10w40
10w30
-10º 0º
0º 20º 40º 60º 80º 100º
10º 20º 30º 40º
-20º
(ºC)
(ºF)
1
2
Figure 3-1
1. Single Viscosity
2. Multi Viscosity
CAUTION: Do not use non-detergent oil or 2-stroke engine oil. It
could shorten the engine’s service life.
NOTE: A 5w30 synthetic oil may be used to improve start ability
for cold weather (temperatures below 40
Checking Oil Level
IMPORTANT:
the engine stopped.
NOTE: Your engine may be equipped with either a short or
for the engine on your unit.
Short Dipstick
1. Remove the oil filler cap/dipstick and wipe the dipstick
Fill
between
high and
low marks
Figure 3-2
2. Insert the cap/dipstick into the oil filler neck, but do not
screw it in.
3. Remove the oil filler cap/dipstick. If the level is low, slowly
add oil until oil level registers between high (H) and low (L).
4. Replace and tighten cap/dipstick firmly before starting
engine.
NOTE: Do not overfill. Overfilling with oil may cause
smoking, hard starting, spark plug fouling, or oil saturation
of air cleaner.
