REF PART
NO. NO.
N° DE N° DE
RÉF PIÈCE DESCRIPTION DESCRIPTION
21 736-0160 Flat Washer .531 ID X .930 OD Rondelle plate .531 DI X .930 DE
22 736-0188 Flat Washer .760 ID X 1.49 OD Rondelle plate .760 DI X 1.49 DE
23 736-0242 Bell. Washer .345 ID X .88 OD X .06 Rondelle Bell..345 DI X .88 DE X .060
24 736-0351 Flat Washer .76 ID X 1.5 OD X .03 Rondelle plate .76 DI X 1.5 DE X .03
25 737-0170 Chain Lube - Belray 6 in 1 or equivalent Lubrifiant de chaine belray 6 in 1 ou equivalent
26 738-0869 Wheel Axle 22.41" Lg. Essieu - roue 22.41 po de lg
27 738-0924 Hex Shld.Scr.1/4-28 x .375 Vis a epaulement 1/4-28 x .375
28 741-0563 Ball Bearing w/snap ring Roulement a billes avec bague
29 741-0598 Hex Flange Brg. .752 ID Roulement hex. .752 DI
30 746-0897 Auger Clutch Cable (w/"Z" fitting) Cable de tariere (avec extremite en ®Z¯)
31 746-0898 Drive Clutch Cable (w/"Z" fitting) Cable d’entrainement (avec extremite ®Z¯)
32 748-0190 Spacer .513 ID X 1.0 Entretoise .513 DI X 1.0
33 756-0625 Cable Guide Roller Guide du cable
34 784-5590 Shift Bracket Frame Bati du commande
35 784-5630A Frame Bati
36 784-5632 Auger Idler Bracket Support du tendeur
37 784-5638 Frame Cover Wheel Drive Couvercle de bati
38 784-5687A Auger Clutch Cable Guide Bracket Support
39 784-5688 Drive Cable Guide Bracket Support de cable d’entrainement
40 784-5689A Front Support Guide Bracket Support
31A-6198
4.26.01
25
Model Wheel Assembly Description Tire Rim
Modèle Ensemble de roue Description Roue Jante
31A-610 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31A-612 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31A-614 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31AE5B6 634-0228-662 16 x 6.5X8X-Trac 734-2031 734-1711-662
31AE640 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE642 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31AE644 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31AE646 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE646 734-1709-499 16.5 x 4.8 Snow Hog 734-1530 734-1708-499
31AE660 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE662 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE664 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE6B0 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE6B3 634-0228-674 16 x 6.5X8X-Trac 734-2031 734-1711-674
31AE6B3 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE6B4 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE6B6 734-1712-662 16 x 6.5 Snow Hog 734-1525 734-1711-662
31AE6C0 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31AE6C3 634-0140-674 15.0 X 5.0 Snow Hog 734-1859 734-1713-674
31AE6Q3 734-1709-674 16.5 x 4.8 Snow Hog 734-1530 734-1708-674
31AH5B3 634-0228-674 16 x 6.5X8X-Trac 734-2031 734-1711-674
31AH5B6 634-0228-662 16 x 6.5X8X-Trac 734-2031 734-1711-662
31BE5B6 634-0228-662 16 x 6.5X8X-Trac 734-2031 734-1711-662
31BE644 634-0114-662 13.0 x 4.0 Snow Hog 734-1732 734-1713-662
31BE646 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31BE660 734-1712-662 16 x 6.5 Snow Hog 734-1525 734-1711-662
31BE662 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31BE664 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31BE6B6 634-0228-662 16 x 6.5X8X-Trac 734-2031 734-1711-662
31BE6C3 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31CE640 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31CE662 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31DE660 734-1709-662 16.5 x 4.8 Snow Hog 734-1530 734-1708-662
31ZH5B3 634-0228-674 16 x 6.5X8X-Trac 734-2031 734-1711-674
WHEEL CHART/TABLEAU DES ROUES ET PNEUS
