MTD 31AS6FEE729 - Page 27

StylesE&F
REE PART
NO. NO.
1 617-04026
2 617-04025
3 656-0012A
4 684-04066
5 684-04045
6 684-04139
7 710-0627
8 710-0788
9 710-1652
10 711-04246A
11 712-0711
12 714-0161
13 716-0231
14 716-0136
15 717-04129A
16 717-04137A
17 790-00082
18 726-0221
19 732-0264
20 736-0242
21 736-04161
22 736-0300
23 736-0105
24 736-0287
25 See Cha_
26 731-04873
731-04877"
27 738-04095A
28 738-0924
29 741-0563
30 741-0245
31 746-0897
32 746-04086
DESCRIPTION
Gear Assembly, 16/44T
Gear Assembly, 16/44T
Disc Assembly, Friction Wheel, .375
Wheel Assembly, Friction, 4.90D
Support Bracket Ass'y, Friction Wheel
REF.
NO.
33
34
35
36
37
PART
NO.
748-0190
756-0625
784-5687A
790-00072
790-00096
DESCRIPTION
Spacer, .508 ID x .75 OD x .68
Roller, Cable
Guide Bracket, Auger Cable
Frame
Guide Bracket, Front, Auger Cable
Shift Assembly, Rod
Screw, 5/16-24 x .750, Gr5
Screw, 1/4-20 x 1.000
Screw, 1/4-20 x .625
Hex Shaft, Drive, .75
Nut, Jam, 3/8-24, Gr2
Key, Hi-pro 3/16 x 5/8
Ring, E Type, .750
Ring, E-Type, .875
Pinion, 16T
Gear, 44T
Idler, Bracket, Drive
Nut, Speed, .500
Extension Spring
Washer, Bell, .340 x .872 x .060
Washer, Flat, .75 x 1.00 x .060
Washer, Flat, .406 x .875 x .059
Washer, Bell, .375 x .870 x .063
Washer, Flat, .793 x 1.24 x .060
Wheel Assembly, Complete
Spacer, 1.25 OD x .75 ID x 3.00
Spacer, 1.25 OD x .75 ID x 1.50
Axle, .75 x 22
Screw, 1/4-28 x .375
Bearing, Ball, 17 x 40 x 12
Bearing, Hex Flange x .75 ID
Cable, Auger, 44.75
Cable, Drive, 41.75
38
39
4O
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
790-00054
790-00055
710-0191
710-0597
710-0654A
710-1245B
712-04064
731-04792
732-0710
736-0247
736-0505
741-0919
748-0234
748-04053
750-04230
750-04303
754-04050
754-0456
756-04109
756-04113
756-04114
790-00062
790-00010
790-00011
710-0896
618-04169
718-04070
735-0243B
Cover, Frame
Roller Bracket, Drive Cable
Screw, 3/8-24 x 1.25, Gr8
Screw, 1/4-20 x 1.00, Gr5
Screw, Sems, 3/8-16 x 1.00
Screw, 5/16-24 x .875, Gr8
Nut, Flange Lock, Nylon, 1/4-20, GrF
Cover, Belt
Spring, Extension, .38 OD x 2.68
Washer, Flat, .406 x 1.25 x.157
Washer, Flat, .34 x 1.50 x. 150
Bearing, Ball, 20 x 47 x 14
Shoulder Spacer
Pulley, Adapter, .75 Dia.
Spacer, .777 OD x .260 ID x.550
Spacer, .875 ID x 1.185 OD
V-Belt, 1/2"
V-Belt, 3/8"
Pulley, Auger, 8.1 x .50
Pulley, Half, 2.600 OD
Pulley, Half, 2.20D
Washer, Bearing, 2.12 OD x .255 ID
Plate, Friction, 12 Pt 4.60 Dia
Plate, Friction, Extrs, 12 Pt 4.60 Dia
Screw, Self-tapping, 1/4-14 x 0.625
Bearing Assembly, Friction Wheel
Hub, Friction Wheel
Friction Wheel Rubber, 4.875 OD
* Found on models with a 22-inch auger housing only.
Wheel Assembly
Complete
634-04144
634-04143
634-04142
634-04141
Wheel Size
13x4
13x5
15x5
16x4.8
Rim Only
634-04151
634-04151
634-04151
634-04140
Tire Only
734-1732
734-1527
734-1859
734-1530
Air Valve
734-0255
734-0255
734-0255
734-0255
NOTE: Snow thrower features and components vary by model. NOT all parts listed above and pictured on the previous page
are standard equipment.
27
