Muffler
Engine exhaust exits the engine via the muffler.
Fuel Cap
Unscrew the fuel cap to add gasoline to the fuel tank . This unit
runs on regular gas.
Oil Fill Cap & Dipstick
Engine oil level can be checked and oil added through the oil fill.
NOTE:
is included in the plastic bag packed the manual in with the unit.
Add the oil as directed in the Setup section. Check the oil level
before each operation to ensure adequate oil is in the engine. For
further instructions, refer to the steps in the Engine Maintenance
section of this manual.
Reverse Handle
halts the tines from engaging.
Forward Clutch Bail & Tine Engagement
The forward clutch bail controls the engagement of the forward
drive of the wheels and tines.
Depth Regulator Lever
back and slide it up or down to engage the notched height
settings.
Handlebar Height Adjustment
The handlebar height is adjustable to three different settings. In
general, adjust the handlebars so they are at waist level when the
tines are 3-4” in the ground.
Rear Tine Shield
The rear tine shield protects the operator from flying debris
while also smoothing out freshly tilled soil.
Side Shield
The side shield is used to maintain clear even rows and may be
adjusted to one of five different positions.
Tines
power-driven shaft.
Wheel Drive Pins
Each wheel is equipped with a wheel drive click pin that secures
the wheel to the wheel shaft. The wheels can be positioned in
Oil Drain
Removing the oil drain plug will drain the oil from the engine.
11se c t i O n 4 — cO n t r O l s a n d fe a t u r e s
