MTD 600 Series Illustrated Parts Manual

11
Auger & Auger Housing
Ref.
Part Number Description
1 731-2635 Cleanout Tool Mount
2 684 -04057A Impeller Assembly, 12"
3 710-0347 Hex Screw, 3⁄8-16 x 1.75
4 710-04484 Hex Washer Screw, 5⁄16-18 x .750
5 710-0451 Carriage Bolt, 5⁄16-18 x .750
6 712-04063 Flange Lock Nut, 5⁄16-18
7 712-04065 Flange Lock Nut, 3/8-16
8 714-04040 Bow-Tie Cotter Pin
9 725- 0157 Cable Tie, 3⁄16 x .05 x 7.4
10 926- 04012 Push Nut, .25 Dia.
11 732-04460 Extension Spring
12 736- 0174 Wave Washer, .625 x .885 x .015
13 736-0242 Bell Washer, .340 x .872 x .060
14 931-2643 Chute Cleanout Tool
15 738-0143 Shoulder Bolt, .496 x .336 x 3⁄8-16
16 938-0281 Shoulder Screw, .625 x .17 x 3⁄8-16
17 738-04124A Shear Pin, .25 x 1.50
18 941-0245 Hex Flange Bearing, .75 ID
19 941-0309 Ball Bearing, .75 ID x 1.85 OD
20 756-04224 Idler Pulley, 2.75 OD
21 790-00075 Bearing Housing, 1.85 ID
22 790-00080B Auger Idler Bracket
23 929-0071A Extension Cord (Electric Start Only)
24 784-5580 Skid Shoe
25 790-00091 Deluxe Skid Shoe
26 710-0703 Carriage Screw, 1⁄4-20 x .75
27 712- 04064 Flange Lock Nut, 1/4-20
28 731-04705D Chute Adapter, 5"
— 731-07525 Chute Adapter, 5" (4-way)
— 731- 07117 Chute Adapter, 5” (side crank)
29 710-0276 Carriage Screw, 5/16-18 x 1.00
30 936-0159 Flat Washer, .349 x .879 x .063
31 941-0475 Plastic Bushing, .380 ID
32 784-5647 Chute Crank Bracket
33* 731-04871 Spacer, 1.250 x .75 ID x 3⁄16 LG
34 710-04071 Carriage Bolt, 5⁄16-18 x 1.00
35 918-04170B Gearbox Assembly, 22"
— 918 -04171B Gearbox Assembly, 24"
— 918 -04172B Gearbox Assembly, 26"
— 918 -04173A Gearbox Assembly, 28"
— 918-04165A Gearbox Assembly, 30"
36 684-04107 Spiral Assembly, LH
Ref.
Part Number Description
37 684-04108 Spiral Assembly, RH
38 684-04266 Auger Housing Assembly, 22”
684-04265 Auger Housing Assembly, 24"
— 684-04270 Auger Housing Assembly, 24” (T-B)
— 684-04264 Auger Housing Assembly, 26"
— 684-04271 Auger Housing Assembly, 26” (T-B)
— 684-04268 Auger Housing Assembly, 28”
— 684-04272 Auger Housing Assembly, 28” (T-B)
— 684-04267 Auger Housing Assembly, 30"
39 731-04870 Spacer, 1.2500 x .75 ID x 1.00
40 736-0188 Flat Washer, .76 x 1.49 x .06
41 741- 0493A Flange Bushing, .800 ID x .910 OD
42 790-00087A Bearing Housing, 1"
43 790 - 0 0117 Shave Plate, 22”
— 790- 00120 Shave Plate, 24"
— 790- 00121 Shave Plate, 26”
— 790 - 0 0118 Shave Plate, 28"
— 790 - 0 0119 Shave Plate, 30"
44 918- 0123A Housing Assembly, RH
45 918-0124A Housing Assembly, LH
46 710-0642 Hex Washer Screw, 1⁄4-20 x .750
47 711-0 4286 Auger Axle, 22"
711- 04285 Auger Axle, 24"
— 711- 04284 Auger Axle, 26"
— 711- 04283 Auger Axle, 28"
— 711- 04282 Auger Axle, 30"
48 914-0161 Hi-Pro Key
49 715- 04021 Dowel Pin, .25 OD x 1.25 LG
50 917- 04126 Worm Shaft, .75 OD
51 917-04861 Worm Gear 20 T, 22”, 24" & 26"
— 917-0528A Worm Gear 20 T, 28"& 30"
52 718-04071 Thrust Collar, .756 ID x .600
53 721-0325 Plug, 1⁄4 x .437
54 721-0327 Oil Seal, .75 x 1.131 x .188
55 936-0351 Flat Washer, .760 ID x 1.50 ID
56 736-3084 Flat Washer, .51 x 1.12 x .06
57 741-0662 Flange Bearing, .75 ID x 1.0 OD x .59
58 741-0663 Flange Bearing, .50 ID x .75 OD x .59
59 946-04230A Auger Drive Cable
60 936 -0159 Washer, Flat, .349 x .879
61 731-05984A Slide Shoe, Poly
62 710-0276 Carriage Screw, 5/16-18 x 1.00
