MTD 600 Series Illustrated Parts Manual

† Not Shown
13
2-Way & 4-Way Extended Chute
Ref.
Part Number Description
1 684-04310A Chute Support Bracket (lrg. block)
— 68 4 - 0 4311A Chute Support Bracket (small block)
2 753- 06151 Chute Control, 4-Way
— 753- 06154 Chute Control, 2-Way
3 710-0262 Bolt, Carriage, 5/16-18 x 1.50, 4-Way
— 710-0451 Bolt, Carriage, 5/16-18 x .750, 2-Way
4 710-04071 Bolt, Carrier, 5/16-18 x 1.00
5 710- 04187 Screw, Hi-Lo, 1/4-15 x 0.50
6 710-04370 Hex Head Screw, 1/4-20 x 3.00
7 710-0627 Hex Head Screw, 5/16-24 x .750
8 710-0895 Screw, Hi-Lo, 1/4-15 x 0.750
9 711- 0 4 4 69A Clevis Pin, 3/8 x 1.87
10 712- 04063 Nut, Flange Lock, 5/16-18
11 712- 04064 Nut, Flange Lock, 1/4-20
12 712-3087 Wing Nut, 1/4-20
13 914-0101 Internal Cotter Pin
14 714-04040 Bow-Tie Cotter Pin
15 920-0284 Wing Knob, 5/16-18
16 731-04427A Chute, Upper, 4-Way
— 731-04426A Chute, Upper, 2-Way
17 731-06440A Chute, Lower
18 731-06451 Cable Guide, Chute Tilt
19 936-0159 Washer, Flat, .349 x .879
20 736-04446 Washer, Flat, .25 x .630
21 738-04367 Screw, Shoulder, .312 x 3.5 x 1/4-20
22 747- 05116 Chute Rod, 3/8 Hex
23 784-5594 Cable Bracket
24 710-04373A Screw, 12-16 x .75
25 711- 05186 Hex Shaft
Ref.
Part Number Description
26 712- 0896 Hexlock Nut, 1/4-28
27 717- 04667 Gear, 14 T
28 717- 04672 Worm
29 731-06906 Gear Cover
30 731-06943A Pawl Lock
31 732-04638C Torsion Spring, .721 ID x .474
32 736-0290 Washer, Flat, .625 x 1.0 x .067
33 738-04391 Screw, Shoulder, .34 x .95 x 1/4-28
34 941-0225 Hex Bearing
35 741-04388A Flange Bearing
36 946-04619B Cable Lock
37 790-00342B Gear Bracket
38 984-04338A Chute Control, 4-Way
— 984-04348 Chute Control, 2-Way
39 710-04353 Screw, #8 x 1.00
40 710-04879 Screw, 8-32 x .750
41 731-04893A Joystick Plug
42 731-07031 Joystick Trigger
43 918-04801A Chute Rotation Gearbox
44 946-04528A 4-Way Cable
946-04477† 4-Way Cable w/Clip
45 984-04324A Shift Assembly
46 753-06152 Gear Set Assembly
47 753-06153 Handle Housing Assembly
48 710 -1256 Screw, #8-18 x 1.250
49 715-04095 Pin, Roll
50 684-04350 Block, Asm Joint
51 715-0150 Pin, Roll
