15
Extended Chute (Crank)
Ref.
Part Number Description
1 918-04933 Chute Rotation Gear Box
2 684-04310A Chute Support Bracket (lrg. block)
— 68 4 - 0 4311A Chute Support Bracket (small block)
3 710-04071 Carriage Bolt, 5⁄16-18 x 1.00
4 710-04370 Hex Screw, 1⁄4-20 x 3.00
5 710-0451 Carriage Bolt, 5⁄16-18 x .750
6 710-0627 Hex Lock Screw, 5⁄16-24 x .750
7 710-1652 Hex Washer Screw, 1⁄4-20 x .625
8 711- 0 4 4 69A Clevis Pin, 3⁄8-1.87
9 712- 04063 Flange Lock Nut, 5⁄16-18
10 712- 04064 Flange Lock Nut, 1⁄4-20
11 712-3087 Wing Nut, 1⁄4-20
12 914-0101 Cotter Pin, .08 x 1.42
13 714-04040 Bow-tie Cotter Pin
14 920-0284 Wing Knob, 5⁄16-18
15 720- 04102 Shift Knob, .390
16 926-0100 Push Cap, 3⁄8
17 731-04426A Upper Chute
18 731-06440A Lower Chute, 5.0
19 936-0185 Flat Washer, .375 x .738 x .063
20 736-04446 Flaw Washer, .25 x .630 x .0515
21 738-04367 Shoulder Screw, .312 x 3.5 x 1/4-20
22 941-0475 Plastic Bushing, .380 ID
23 747-05386 Chute Crank
24 790-00341 Support Rod Bracket
25 717- 04667 Gear Assembly
26 710-04373A Screw, 12-16 x .75
27 712-04065 Flange Lock Nut, 3/8-16
28 717- 04672 Worm
29 731-07529A Gear Cover
30 732-04756 Compression Spring, .39 x .60 x .88
31 736-3072 Flat Washer, .380 x .93 x .110
32 736-0290 Flat Washer, .625 x 1.0 x .067
33 941-0225 Hex Bearing
34 741-04388A Flange Bearing
35 790-00342B Gear Bracket
36 711- 05329 Worm Shaft
