MTD 600 Series Illustrated Parts Manual

17
2-Way Extended Chute
Ref.
Part Number Description
1 918-04933 Chute Rotation Gearbox
2 68 4 - 0 4311A Chute Support Bracket
3 984-04325A Chute Control, 2-Way
4 710-0262 Bolt, Carriage, 5/16-18 x 1.50
5 710-04071 Bolt, Carrier, 5/16-18 x 1.00
6 710- 04187 Screw, Hi-Lo, 1/4-15 x 0.50
7 710-04370 Hex Head Screw, 1/4-20 x 3.00
8 710-0599 Screw, TT, 1/4-20 x .500
9 710-0627 Hex Head Screw, 5/16-24 x .750
10 710-0895 Screw, Hi-Lo, 1/4-15 x 0.750
11 710-1652 Screw, 1/4-20 x .625
12 711- 0 4 4 69A Clevis Pin, 3/8 x 1.87
13 712-04063 Nut, Flange Lock, 5/16-18
14 712-04064 Nut, Flange Lock, 1/4-20
15 712-3087 Wing Nut, 1/4-20
16 914-0101 Internal Cotter Pin
17 714-04040 Bow-Tie Cotter Pin
18 920-0284 Wing Knob, 5/16-18
19 720-04102 Shift Knob, .390
20 926-0100 Push Cap, 3⁄8
21 931-04425B Upper Chute
22 731-06440A Lower Chute, 5.0
Ref.
Part Number Description
23 731-06451 Cable Guide, Chute Tilt
24 936-0159 Washer, Flat, .349 x .879
25 936-0185 Flat Washer, .375 x .738 x .063
26 736-04446 Washer, Flat, .25 x .630
27 738-04367 Shoulder Screw, .312 x 3.5 x 1/4-20
28 941- 0475 Plastic Bushing, .380 ID
29 747- 05386 Chute Crank
30 784-5594 Cable Bracket
31 790- 00341 Support Rod Bracket
32 710-04373A Screw, 12-16 x .75
33 711- 05329 Worm Shaft
34 712-04065 Flange Lock Nut, 3/8-16
35 717- 04667 Gear Assembly
36 717- 04672 Worm
37 731-07529A Gear Cover
38 732-04756 Compression Spring, .39 x .60 x .88
39 736-0290 Flat Washer, .625 x 1.0 x .067
40 736-3072 Flat Washer, .380 x .93 x .110
41 941-0225 Hex Bearing
42 741-04388A Flange Bearing
43 790-00342B Gear Bracket
