Standard 2-Way Chute
Ref.
Part Number Description
1 631-04131B Lower Chute Assembly
2 731-04912B Lower Chute
3 710-04071 Carriage Bolt, 5⁄16-18 x 1.00
4 710-0451 Carriage Bolt, 5⁄16-18 x .750
5 712- 04063 Flange Lock Nut, 5⁄16-18
6 920-0284 Wing Knob
7 731-04426A Upper Chute
8 731-04869A Flange Keeper
9 684-04104 Chute Crank
10 914-0104 Cotter Pin, .072 x 1.13
11 720-0201A Crank Knob
12 926-0100 Push Cap, 3⁄8
13 735-0234 Rubber Grommet
14 936-0185 Flat Washer, .375 x .738 x .063
15 747-04263 Eye Bolt
16 684-04350 Joint Assembly
17 684-04351 Chute Crank
18 710-0599 Taptite Screw, 1/4-20 x .500
19 914-0101 Cotter Pin, .08 x 1.42
20 715-04095 Pin, .156 x .875
21 710-04484 Taptite Screw, 5/16-18 x 2.25
22 720-04102 Shift Knob
23 747-05154 Upper Chute Rod
24 747-05157 Chute Rod Eye Bolt
25 747-05159 Lower Chute Rod
26 710-0276 Carriage Screw, 5/16-18 x 1.00
27 936-0159 Flat Washer, .349 x .879 x .063
28 941- 0475 Plastic Bushing, .380 ID
29 784-5647 Chute Crank Bracket
