MTD 600 Series Illustrated Parts Manual

5
E/F-Style Panel
Ref.
Part Number Description
1 710-04484 Taptite Screw, 5/16-18 x .750
2 631- 04133A Clutch Lock Handle Assembly, LH
— 631- 04134B Clutch Lock Handle Assembly, RH
3 684-04105B Engagement Assembly, LH
4 684-04106C Engagement Assembly, RH
5 684-04250 Clutch Pivot Lock Rod Assembly
6 710-04326 Hex Washer Screw, #8-16 x .50
7 710-04586 Hex Washer Screw, 1⁄4-20 x .625
— 710-0606 Hex Head Screw, 1/4-20 x 1.50 +
8 710-0572 Carriage Screw, 5/16-18 x 2.25
9 710 -1233 Machine Screw, #10-24 x 1.375
10 710-3069 Socket Screw, 1⁄4-20 x .50
11 712- 04063 Flange Lock Nut, 5⁄16-18
12 920-0284 Wing Knob
13 712-04081A Hex Nut, 1⁄4-20
14 914-0145 Click Pin, .092 x 1.64
15 720 -0274 Grip, 1.0 ID x 5.0 LG
16 720-04039 Shift Knob
17 725-05153 Snow Thrower Harness ^
18 925-1658 Halogen Lamp ^
19 925-1672 Lens/Lamp Assembly Housing ^
Ref.
Part Number Description
20 926-0154 Cable Tie
21 731-04894D Lock Plate
22 731-04896B Clutch Lock Cam
23 732-0193 Compression Spring, .39 x .60 x .88
24 732-04219C Clutch Lock Spring
25 732-04238 Torsion Spring, .8156 ID x .3038
26 749-04138A Lower Handle
27 935-0199A Rubber Bumper, .62 OD x .22 Thick
28 736-0262 Flat Washer, .385 x .870 x .092
29 749 -04190A Upper RH Handle
30 738 - 0 4118 Shoulder Bolt, 5⁄16-18 x .905
31 749-04191A Upper LH Handle
32 738-04348 Shoulder Screw, .437 x 1.345 x 1⁄4-20
33 946- 04397A Speed Selector Cable
34 747-1136 Headlight Retainer ^
35 790-00209 Handle Panel w/ Light ^
— 790-00219 Handle Panel w/o Light
36 712- 04064 Flange Lock Nut, 1/4-20 +
37 790 -00313 Speed Shift Lever
38 790-00248C Panel Bracket
— 729-04035 Amp Connector
+ Models without Clutch Lock
^ Models with Light
