MTD 600 Series Illustrated Parts Manual

7
K/L-Style Panel
Ref.
Part Number Description
1 710-04484 Screw, Taptite, 5/16-18 x .750
2 631- 04134B Clutch Lock, RH
— 631- 04133A Clutch Lock, LH
3 931-05348A Handle Panel Gray, includes 39 & 40
931-04183 Handle Panel Black, includes 39 & 40
4 684-04105B Auger Engage, Black
5 684-04106C Drive Engage, Black
6 684-04250 Pivot Rod
7 710-04326 Screw, Plastite, 8-16 x .50
8 710-04586 Screw, Taptite, 1/4-20 x 1.625
9 710-0837 Screw, 10-16 x 0.625
10 710 -1233 Screw, 10-24 x 1.375
11 710-3069 Screw, 1/4-20 x .50
12 712- 04064 Nut, Flange Lock, 1/4-20
13 712-04081A Nut, Hex, 1/4-20
14 914-0145 Click Pin, .092 x 1.64
15 720-04039 Shift Knob
16 725-0157 Cable Tie, 7”
17 925-1629 Lamp, 12.8V, 357cc Engine
18 710-0572 Screw, Carriage, 5/16-18 x 2.25
19 725-04393 Heated Grip Switch
20 925-1649 Lamp Socket
21 725-05149 Heated Grip
— 720-0274 Grip
Ref.
Part Number Description
22 926- 0154 Cable Tie, Push Mount
23 731-04894D Plate, Lock
24 731-04896B Cam, Clutch Lock
25 732-0193 Compression Spring, .39 x .60 x .88
26 732-04219C Clutch Lock Spring
27 732-04238 Torsion Spring, 0.8156 x .3038
28 935-0199A Rubber Bumper
29 936-0267 Washer, Flat, .385 x .87
30 738- 04125 Screw, Shield, .374 x 1.05
31 738-04348 Screw, Shoulder, .437 x 1.345 x 1/4-20
32 946-04396A Speed Selector Cable
33 790-00248C Panel Bracket
34 79 0 - 0 0311A Shift Lever
35 920-0284 Wing Knob
36 749 -04138A Lower Handle
37 749 -04190A Upper RH Handle
38 749-04191A Upper LH Handle
39 731-05320 Lens Panel
40 777X41803 Lens Label
— 925- 04137 Harness Assembly
— 725-05148 Heated Grips Harness, 357cc Engine
— 725-04694A
Heated Grips Harness, 179cc & 208cc
Engines
