MTD 615 - Page 21

21
Model Series 615, E6A5, E645 & E665
Ref.
No.
Part
No.
Description
1. 712-0116 Lock Jam Nut 3/8-24
2. 756-0178 Flat Idler
3. 784-5632B Auger Idler Arm
4. 710-0459A Hex Cap Screw 3/8-24 x 1.50
5. 738-0281 Shoulder Screw
6. 736-0167 Flat Washer
7. 732-0611 Extension Spring
8. 712-3068 Hex Nut 5/16-18
9. 712-3010 Hex Nut 5/16-18
10. 736-0119 Lock Washer 5/16
11. 05931A Housing
12. 741-0309 Ball Bearing
13. 710-0451 Carriage Bolt 5/16-18
14. 705-5226 Reinforcement Chute
15. 684-0052C 22” Housing Assembly
684-0039D 24” Housing Assembly
684-0040D 26” Housing Assembly
18. 736-0242 Bell Washer
19. 741-0475 Bushing
20. 784-5647 Chute Crank Bracket
21. 731-1379C Chute Adapter
22. 712-3027 Hex Lock Nut 1/4-20
23. 736-0463 Flat Washer
24. 710-0451 Carriage Bolt
25. 710-0703 Carriage Screw 1/4-20 x .75
26. 710-0726 Hex Washer Screw 5/16-12 x .75
27. 736-0169 Lock Washer 3/8
28. 712-0798 Hex Nut 3/8-16
29. 710-0451 Carriage Bolt 5/16-18 x .75
30. 784-5580 Snow Shoe
31. 736-0242 Bell Washer
33. 784-5576 22” Shave Plate
784-5581A 24” Shave Plate
784-5579A 26” Shave Plate
35. 684-0065 Impeller Assembly
36. 715-0114 Pin
37.* 618-0152A 22” Gear Assembly
618-0120A 24” Gear Assembly
618-0121A 26” Gear Assembly
38. 605-5252A Spiral 22” RH
605-5188A Spiral 24” RH
605-5192A Spiral 26” RH
39. 736-0188 Flat Washer
40. 741-0493A Flange Bushing
41. 605-5253A Spiral 22” LH
605-5189A Spiral 24” LH
605-5193A Spiral 26” LH
42. 710-0890A Shear Bolt 5/16-18 x 1.5
43. 712-0429 Lock Nut 5/16-18
44. 741-0245 Hex Flange Bearing
45. 784-5618 Bearing Housing
46. 737-0318 Grease
47. 731-2643 Chute Clean-out Tool
48. 731-2635 Mount, Chute Clean-out Tool
Ref.
No.
Part
No.
Description
* See page 20 for breakdown of this assembly.
