MTD 615 - Page 25

25
Models Series 615, E6A5E, E645E & E665E
Ref.
No.
Part
No. Description
1. 705-5234A Clutch Lever Assembly - RH
2. 705-5233A Clutch Lever Assembly - LH
3. 720-0274 Grip
4. 784-5717A Control Panel Assembly (615, E6A5E)
784-5718A Control Panel Assembly (E645, E665)
5. 735-0199A Bumper Rubber
6. 749-0910C Handle RH
7. 749-0911C Handle LH
8. 629-0058 Light Harness †
9. 741-0475 Bushing Plastic .380
10. 784-5647 Bracket
11. 746-0778 “Z” Fitting
12. 712-0121 Hex Nut
13. 746-0897 Auger Clutch Cable
14. 746-0898B Drive Clutch Cable
15. 712-3010 Hex Nut 5/16-18
16. 736-0119 Lock Washer 5/16
17. 750-1032 Spacer
18. 710-3103 Hex Hd. Cap Screw 5/16-18 x 2.00
19. 710-0262 Carriage Bolt 5/16-18 x 1.5
20. 726-0100 Push Rod Cap
21. 720-0201A Chute Crank Knob
22. 715-0138 Roll Pin
23. 705-5204A Chute Crank Assembly
24. 736-0242 Bell Washer .340 ID x .873 OD
25. 747-0697 Eyebolt
26. 735-0234 Rubber Grommet
27. 720-0223 Grip
28. 705-5265 Speed Selector Plate (1 Rev)
705-5231 Speed Selector Plate (2 Rev)
29. 710-1652 Hex Washer Screw 1/4-20 x .625 †
30. 710-1003 Hex Washer Screw #10 16 x .625 †
31. 710-0599 Hex Washer Screw 1/4-20 x .50
32. 712-0415 Hex Nut †
33. 725-1300 Headlight 18 Watt †
34. 731-1317 Headlight Cover †
35. 747-0904 Shift Lever
36. 710-3015 Hex Cap Screw 1/4-20 x .75
37. 712-3027 Hex Lock Nut 1/4-20
38. 732-0733 Shift Lever Support
39. 710-0809 Hex Washer
40. 784-5599 Handle Tab
41. 710-04039 Hex Cap Screw 5/16-18 x 2”
42. 710-1880 Hex Cap Screw 5/16-18 x .75
43. 736-0185 Flat Washer 3/8 ID x .738 OD
44. 714-0104 Cotter Pin
45. 712-0429 Hex Lock Nut 5/16-18
46. 736-0159 Washer 5/16
47. 731-0921 Upper Chute
48. 720-0284 Knob 5/16-18
49. 710-04071 Carriage Screw 5/16-18 x 1.0
50. 710-0451 Carriage Bolt 5/16-18 x .75
51. 731-1300B Lower Chute
52. 712-3027 Hex Lock Nut 1/4-20
53. 731-0851A Chute Flange Keeper
54. 710-3015 Hex Cap Screw 1/4-20 x .75
55. 712-3068 Hex. Wash. Locknut 5/16-18 Thd.
56. 705-5275 LH Handle Support Brkt.
- 705-5274 RH Handle Support Brkt.
Ref.
No.
Part
No. Description
†
If Equipped
