MTE Sine Wave Filter - Mechanical Data; 200 - 230 Volts

Sine Wave 2-8 kHz Series A Filter
8 Part No. INSTR-020 REL. 080310
5 Mechanical Data
200 - 230 Volts
Table 10
Open NEMA 1* NEMA 3R
Filter
Amps
Cat PN.
WT
Lbs
Fig.
Cat PN.
WT
Lbs
Fig.
Cat PN.
WT
Lbs
Fig.
3
SWAP0003A
16
3
SWAGA0003A
32
8
SWAWA0003A
89
10
5
SWAP0005A
21
3
SWAGA0005A
37
8
SWAWA0005A
94
10
7
SWAP0007A
24
3
SWAGA0007A
40
8
SWAWA0007A
97
10
9
SWAP0009A
24
3
SWAGA0009A
40
8
SWAWA0009A
97
10
12
SWAP0012A
27
3
SWAGA0012A
43
8
SWAWA0012A
100
10
17
SWAP0017A
31
3
SWAGA0017A
47
8
SWAWA0017A
104
10
22
SWAP0022A
32
3
SWAGB0022A
57
9
SWAWB0022A
133
11
30
SWAP0030A
38
4
SWAGB0030A
60
9
SWAWB0030A
136
11
45
SWAP0045A
47
4
SWAGB0045A
69
9
SWAWB0045A
145
11
55
SWAP0055A
55
4
SWAGB0055A
77
9
SWAWB0055A
153
11
70
SWAP0070A
60
4
SWAGC0070A
215
9
SWAWC0070A
249
11
85
SWAP0085A
73
A17 & B
SWAGC0085A
228
12
SWAWC0085A
262
12
110
SWAP0110A
92
A19 & B
SWAGC0110A
247
12
SWAWC0110A
281
12
135
SWAP0135A
100
A19 & B
SWAGC0135A
255
12
SWAWC0135A
289
12
160
SWAP0160A
121
A19 & B
SWAGC0160A
271
12
SWAWC0160A
305
12
200
SWAP0200A
167
A2 & C
SWAGC0200A
327
13
SWAWC0200A
351
13
250
SWAP0250A
196
A3 & C
SWAGD0250A
479
13
SWAWD0250A
531
13
320
SWAP0320A
228
A4 & C
SWAGD0320A
511
13
SWAWD0320A
563
13
