MTE Sine Wave Filter - Model Number Codes

Sine Wave 2-8 kHz Series A Filter
3
Part No. INSTR-020 REL. 080310
3. MODEL NUMBER CODES
Model Code Part Number Configuration
SW A X Y _ _ _ _ X YY
Sine Wave filter
Series Version. A, X Options
“X” denotes Non standard Configurations 01 NC Overtemp
Mechanical Configuration P = Panel Mount
G = General Purpose
NEMA 1 or 2
W = NEMA 3R
Indicates Physical Size: A, B, C, D, etc. (A is smallest)
Current Rating (i.e. 0045 is 45 Amps)
Voltage
D 440 – 480
E 550 – 600
