MTE Sine Wave Filter - Fan Power

Sine Wave 2-8 kHz Series A Filter
34 Part No. INSTR-020 REL. 080310
Fan Power
All enclosed part number filters listed below have fans that require a source of
clean 115 volt 50/60 Hz power.
Table 10
Filter Voltage PN NEMA1 PN NEMA3R Cab Fans total load amps
SWAGC0200A SWAWC0200A 26C2/3 2 x 6"
0.48
SWAGD0250A SWAWD0250A 30C2/3 2 x 10"
0.96
200-230 VAC
SWAGD0320A SWAWD0320A 30C2/3 2 x 10"
0.96
SWAGC0160D SWAWC0160D 26C2/3 2 x 6"
0.48
SWAGD0200D SWAWD0200D 30C2/3 2 x 10"
0.96
SWAGD0250D SWAWD0250D 30C2/3 2 x 10"
0.96
SWAGD0305D SWAWD0305D 30C2/3 2 x 10"
0.96
SWAGD0365D SWAWD0365D 30C2/3 2 x 10"
0.96
SWAGD0415D SWAWD0415D 30C2/3 4 x 10"
1.92
SWAGD0515D SWAWD0515D 30C2/3 4 x 10"
1.92
SWAGE0600D SWAWE0600D 42C2/3 4 x 10"
1.92
380-480 VAC
SWAGE0720D SWAWE0720D 42C2/3 4 x 10"
1.92
SWAGD0130E SWAWD0130E 30C2/3 2 x 10"
0.96
SWAGD0160E SWAWD0160E 30C2/3 2 x 10"
0.96
SWAGD0200E SWAWD0200E 30C2/3 2 x 10"
0.96
SWAGD0250E SWAWD0250E 30C2/3 2 x 10"
0.96
SWAGD0305E SWAWD0305E 30C2/3 2 x 10"
0.96
SWAGD0365E SWAWD0365E 30C2/3 2 x 10"
0.96
SWAGE0415E SWAWE0415E 42C2/3 4 x 10"
1.92
SWAGE0515E SWAWE0515E 42C2/3 4 x 10"
1.92
SWAGE0600E SWAWE0600E 42C2/3 4 x 10"
1.92
550-600 VAC
SWAGE0720E SWAWE0720E 42C2/3 4 x 10"
1.92
Note: The clean 115 volt control power to the fans is customer supplied.
A terminal block labeled “Fan Power” is provided inside the enclosure for this purpose
