RL Series
Line/ load Reactors
USER MANUAL
PART NO. INSTR -011
REL. 150109 REV. 006
© 2015 MTE Corporation

Table of Contents

Other manuals for MTE RL Series

Preview: Technical Reference Manual
Technical Reference Manual50 pages

Questions and Answers

  • K
    Kerri AndersonJul 28, 2025
    What to do if the MTE RL Industrial Electrical filter output voltage is not within specification?
    • M
      Mr. Dalton MasonJul 28, 2025
      If the filter output voltage isn't within the specified range, several factors could be at play. First, check that the reactor input voltage is within its specified tolerance, referring to the reactor service conditions and performance specifications. Also, verify that the source impedance is within the acceptable range, again consulting the reactor's specifications. The drive setup parameter might not be configured for an input reactor, so you should consult the drive manufacturer to update the setup. Finally, extreme voltage transients, like switching between voltage sources, can cause issues. Avoid source switching without proper phase synchronizing or a reasonable time delay.
  • M
    Michael HuynhAug 11, 2025
    How to troubleshoot no line voltage at MTE Industrial Electrical reactor output terminals?
    • H
      harmonjoelAug 11, 2025
      If there's no line voltage at the reactor output terminals, the issue could stem from a couple of things. First, ensure that the power to the reactor is turned on. If the power is on, check the external line fuses; if one or more are blown, verify the continuity of line fuses in all phases and replace any that are not working.

Summary

Important User Information

Notice for User Information

Provides critical notices regarding the MTE Series RL Line/Load Reactors and their application.

Important Safety Information

Safety Warnings for Installation and Operation

Highlights critical safety warnings for qualified electricians and general users regarding high voltage and proper grounding.

Model Number Coding System

Product Specifications Overview

General Reactor Specifications

Details standard impedance values, service factor, overload ratings, voltage, frequency, insulation, and temperature ratings.

Product Specifications: Approvals and Materials

Agency Approvals and Certifications

Lists agency approvals such as UL, CSA, and CE markings for the MTE reactors.

Material and Construction Details

Product Specifications: Performance Features

PWM;IGBT Protection and Harmonic Attenuation

De-Rating Curves

Mounting Compatibility and Dimensions

Mechanical Details for Open Reactors

Mechanical Details for Open Reactors (Continued)

NEMA 1 Enclosure Mechanical Data

NEMA 1 Enclosure Mechanical Data (Continued)

Technical Data (Part 1)

Technical Specifications Table (Watts Loss, Wire Range, Torque, Inductance, Fund;Max Amps)

Lists technical data including watts loss, wire range, terminal torque, inductance, and current ratings for RL reactors.

Technical Data (Part 2)

Continued Specifications Table

Continues the technical data table, listing specifications for higher current/larger models.

Installation Instructions

Open Reactor Installation Guidelines

Provides guidance on installing open construction reactors, including mounting positions and clearances.

NEMA 1 Reactor Installation Guidelines

Details installation requirements for NEMA 1 enclosed reactors, including conduit entry and clearances.

Power Wiring Connection and Grounding

Power Wiring Regulations and Recommendations

Covers regulations for power wiring, fuse selection, conductor ratings, and terminal torque.

Grounding Requirements

Specifies grounding procedures for both enclosed and open reactors for safety.

Typical Connection Diagrams

Line and Load Reactor Connection Examples

Illustrates typical wiring diagrams for LINE, LOAD, and multi-reactor applications.

Single Phase Connection Diagram

Sequence of Operation and Startup

Pre-Startup Checks and Procedures

Outlines essential steps before startup, including safety checks, ground connections, and wiring verification.

Startup Safety Precautions

Critical Warnings Before Startup

Emphasizes critical warnings and extreme caution required when dealing with line potential and high voltage during startup.

MTE RL Series Specifications

General IconGeneral
BrandMTE
ModelRL Series
CategoryIndustrial Electrical
LanguageEnglish
